HP 4000

7-28
Parts and Diagrams
HP Designjet 4000/4020 Printer Series Service Manual
Miscellaneous Parts
Arc Assemblies
Reference
on
Drawing
HP Part Number Quantity Description/Comments
1Q1273-600971Right Arc
2 Q1273-60098 1 Left Arc
-Q1273-600611
Preventive Maintenance Kit (Includes
Carriage Assembly (without Carriage PCA),
Ink Supply Tubes and Trailing Cable, Scan-
Axis Motor, Belt, Encoder Strip (includes
Spring and Nut but does not include Encoder
Reader), Most Left and Middle Left Spittoons),
Scraper and the Media-Axis Drive Motor
Brake (with the corresponding support Part)
-Q1273-601251
2 Sheets of HP Productivity Gloss Media for
Service Advance Calibration
-Q1273-601301
Labels Kit (includes the Serial Number
Label, I/O Connector Label and the Main
PCA Cover Removal Label)
- 5961-3589 1 Power Cord (2.5 meters) for Australia
- 812 0 - 6899 1
Power Cord (2.5 meters) for most European
Countries, Korea, Indonesia, Portugal,
Germany, Spain, France, Italy and Arabic
Countries
- 812 0 - 6898 1
Power Cord (2.5 meters) for Singapore,
Arabic Countries and United Kingdom
- 812 0 - 6896 1
Power Cord (2.5 meters) for India, South
Africa
- 8121- 0917 1
Power Cord (2.5 meters) for USA, Mexico,
Canada, Taiwan, Japan and Arabic
Countries
- 8121- 0922 1
Power Cord (2.5 meters) for Brazil, Thailand
and Philippines
-5961-35901
Jumper Cord for Chili, Uruguay and
Argentina
-8120-69801
Power Cord (2.3 meters) for Chili and
Uruguay (final cable that is connected to
5961-3590)
- 812 0 - 6869 1
Power Cord (2.3 meters) for Argentina (final
cable that is connected to 5961-3590)
- 5961-3588 1 Power Cord (2.5 meters) for China
