8-25
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
9. Disconnect the Aerosol Fan Tube from the
Chassis.
10. Remove the Service Station from the Printer.
After installing the NEW Service
Station, make sure you perform the
following Service Utility:
îš„ Reset Counter PHC spittoon
⇒
Chapter
4.
After installing the NEW Service
Station, make sure you perform the
following Service Calibration:
îš„ Service Station Calibration
⇒
Chapter 5.
To Next Page
