8-57
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
12. Insert the Trailing Cable into all the Cable
Holders and insert all the Cable Holders
into the slots of the Ink Tube Carrier.
13. Install the Ink Supply Tubes, Trailing Cable
and Carriage Power Supply Cable into the
Printer. (The rest of the installation
procedure is the same as the removal
procedure but in reverse).
To Next Page
