8-66
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
8. Install the tube with the blue connector into
the slot in the Ink Supply Station.
9. Connect the tube with the blue connector
to the Ink Supply Tubes. Be carefull not to
cut your hand on any sharp surfaces.
10. Install the ISS
⇒
Page 8-60
.
11 . Install the Left Connector Cover
⇒
Page 8-
19
.
12. Install the Left Cover
⇒
Page 8-9
.
To Next Page
