8-143
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
9. Carefully remove the Right Trim from the
Printer.
10. Carefully release the clip securing the
Media Lever Sensor from the Right Trim
and remove from the locating pins.
11 . Release the Media Lever Sensor Cable
from the four clips on the Vacuum Fan.
1
2
