8-164
Removal and Installation
HP Designjet 4000/4020 Printer Series Service Manual
3. Place the spring on the top hook.
4. Stretch the spring and loop the spring on
the bottom hook.
5. Check that the Spindle Lever is installed
correctly as shown here.
