System Error Codes
HP Designjet 4000/4020 Printer Series Service Manual
The following table explains the
XX
part of the System Error Code or Warning:
Code Component/System
01.0 Main PCA/Electronics Module (Gamut)
01.1 Add-on Electronics Module (Printmech)
01.2 ISS Electronics Module
02 Carriage
02.1 Carriage PCA
03 Power Supply Unit
04 Network Card
05 Formatter
05.1 Fan of the Formatter
05.2 Processor of the Formatter
05.3 Memory of the Formatter
06 Hard Disk Drive
07 Interconnect PCA
08 Front Panel
11 Trailing Cable
12 C a rr i a g e Fl e x C i rcu i t
13.n Cable from cartridge n to ISS PCA
17 Interconnect Cable
21 Ser vice Stat i o n
22 Ink Supply Station
23 Pressure System (APS)
24 Ink Delivery Tubes
25 Spittoon
26n Ink Cartridge (color n)
27n Printhead (color n)
28n Setup Printhead (color n)
29n Printhead Cleaner (color n)
31 C u t t e r
32 Take-up Reel
33 Sheet Feeder
34 Dryer/Blower
35 Cleanout Assembly
36 Duplexer
37 ARSS/Rollfeed
38 Output Tray
39 Paper Loading Failure
41 Pa p e r- A xi s M o t o r
42 Scan-Axis Motor
43 Vacuum Fan
44 Aerosol Fan
Items in red are
not applicable
to this printer.
