ECC800 Data Center Controller
User Manual (for ECC800-Pro)
5 Power-On Commissioning
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
113
Address
Toggle
Switch 1
Toggle
Switch 2
Toggle
Switch 3
Toggle
Switch 4
Toggle
Switch 5
Toggle
Switch 6
4
OFF
OFF
ON
OFF
OFF
OFF
5
ON
OFF
ON
OFF
OFF
OFF
6
OFF
ON
ON
OFF
OFF
OFF
7
ON
ON
ON
OFF
OFF
OFF
8
OFF
OFF
OFF
ON
OFF
OFF
9
ON
OFF
OFF
ON
OFF
OFF
10
OFF
ON
OFF
ON
OFF
OFF
11
ON
ON
OFF
ON
OFF
OFF
12
OFF
OFF
ON
ON
OFF
OFF
Step 4 Add the cabinet electronic clasp locks.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Create a cabinet view in Smart Module View on the home page.
3. Add a cabinet electronic clasp lock.
Table 5-15 Adding an E-LOCK
Path
Parameter
Name
Setting
Choose System Settings >
Device Management and
click Add Device. The
parameters for adding
devices are displayed.
Device
attribute
Elock
Device type
E-LOCK
Connect to
ECC800
Communicatio
ns port
odd-numbered cabinets: COM2
even-numbered cabinets: COM3
Device address
Enter the actual device address of the
cabinet electronic clasp lock.
4. Click Test Connect to check whether the connection between the cabinet electronic
clasp lock and the ECC800-Pro is normal.
− If the connection is normal, click Confirm. The connected devices are displayed in
the Number of connected devices list.
− If the connection is abnormal, check whether the device is properly connected to the
ECC800-Pro, whether the device and ECC800-Pro are running properly, and
whether the parameter settings are consistent with the device parameters.
5. Connect the electronic locks of other cabinets.
