3 Device Description
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
72
(7) RF_Z antenna port
(8) BCB_1–BCB_4 ports
(BCB_2–BCB_4 reserved)
(9) BCB_OUT and BCB_IN
ports
(10) Networking switch
(11) PWR indicator
(12) RUN indicator
(13) ALM indicator
(14) RF_Z indicator
(15) Delivered antenna
Figure 3-46 iBOX bottom view
(1) Fastener
(2) Micro SD card slot
(3) Default button (IP
reset)
(4) ADDR dual in-line package (DIP) switch (RS485
communications address)
(5) 12 V 2 A port (power
input)
Power Port
Figure 3-47 Power port pins
