ECC800 Data Center Controller
User Manual (for ECC800-Pro)
Copyright © Huawei Technologies Co., Ltd.
Table 3-71 12 V, 2 A port pin definitions
An external power module
is adopted to supply 12 V
DC operating voltage.
Table 3-72 –48 V, 0.5 A port pin definitions
The system provides 48 V
DC operating voltage in this
scenario.
POE Port
Figure 3-48 POE port pins
Table 3-73 POE port pin definitions
Supports power supply
through the POE port. The
terminal is an RJ45 terminal
with an indicator.
