3 Device Description
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
79
Indicat
ors
Color
Meaning
Status
Description
Measure
than the value
of iBAT
number.
indicators.
Off
The actual
number of
online
devices
equals the
value of
iBAT
number.
Requires no handling.
PWR
Green
Power
indicator
Steady on
Board power
indicator.
Requires no handling.

If an indicator blinks at long intervals, it is blinking at 0.5 Hz, that is, on for 1s and then off for 1s.

If an indicator blinks at short intervals, it is blinking at 4 Hz, that is, on for 0.125s and then off for
0.125s.

If an indicator blinks at super short intervals, it is blinking at 10 Hz, that is, on for 0.05s and then off
for 0.05s.

Blinking intermittently at short intervals means an indicator blinks at super short intervals for 0.5s
and then remains off for 0.5s.
Networking Switch
Table 3-81 Networking switch description
Name
Definition
Function
Button pressing
Press the button for
less than 1s.
iBOX blinking function
Button pressing
Press and hold the
button for more than
1s but less than 5s.
Creates a network if no network has
been created. Switches between network
organization and data transmission if a
network has been created.
Button holding down
Press and hold the
button for more than
10s but less than 20s.
Clears the current network (including
the network parameters of all the online
iBATs).
