Huawei FusionModule2000 User Manual

FusionModule2000 Smart Modular Data Center
Installation Guide
10 Installing the Aisle Containment
Issue 02 (2018-03-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
122
Table 10-6 Sliding door components
No.
Name
Remarks
1
Aisle door fittings
Seal the bottom of a 2000
mm high end cabinet.
2
Posts
The door frame consists of
an upper frame mounting kit
and the left and right posts.
3
Upper frame mounting kit
4
Guide rail
Hangs a sliding door.
5
Glass doors
Slide rightward and
leftward.
6
Stop blocks at the end of the
guide rail
Limit the position of the
door at both ends of the
guide rail.
7
Dampers
The dampers are left and
right sensitive.
8
Hanging kits
The dampers are left and
right sensitive.
9
Door boxes
The door boxes are left,
middle, and right sensitive.
Preparations
Tools: adjustable wrench, torque wrench, Phillips screwdriver, flat-head screwdriver, socket
wrench, step ladder, level
Materials: sliding doors and accessories
Procedure
Step 1 Install the door frame.
1. Pull the post side panel upwards off the clips, as shown by (1) and (2) in Figure 10-32.
2. Secure the left and right posts to the upper frame mounting kit using eight M6x16 screws,
as shown by (3) in Figure 10-32.

To facilitate assembly, lay the posts and upper frame installation kit on the floor.

After the assembly is complete, verify that the posts are flush with the upper frame mounting kit.
