FusionModule2000 Smart Modular Data Center
Installation Guide
6 Installing the Network Cabinet, IT Cabinet, and Battery
Cabinet
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6.3 (Optional) Taking out rPDU Cables
Preparations
Tools: diagonal pliers
Procedure
Step 1 Remove the rodent-proof mesh on the top of the rPDU in a cabinet, and take out the rPDU
cables from the top.
Step 2 Lay out the rPDU cables on the cabinet top, and reinstall the rodent-proof mesh.
Cut the rodent-proof mesh based on the cable thickness using diagonal pliers. If the opening is
too large, unwanted things may fall into the cabinet through the opening.
----End
Follow-up Procedure
Before connecting the power plug of a device to the rPDU, loosen the locking device on the
rPDU. After connecting the power plug, tighten the locking device.
6.4 (Optional) Taking out Industrial Connectors
Prerequisites
The rPDUs are equipped with industrial connectors.
Preparations
Tools: diagonal pliers
Procedure
Step 1 Remove the rodent-proof mesh on the top of the rPDU in a cabinet, and take out the two
industrial connectors from the top.
