Move the adjustable feet of the air conditioner base to the cabinet front (close to the front door
of the cabinet).
Step 3 Secure the adjustable feet using the four M6 screws removed before.
Figure 4-12 Securing adjustable feet
----End
4.3.2 (Optional) Adjusting Adjustable Feet of Air Conditioner and
PDC Bases (600 mm Wide)
Context
A 600 mm wide adjustable base is used for a 600 mm wide air conditioner or PDC. The BOM
number of a 600 mm wide adjustable bases is 21151128.
