FusionModule2000 Smart Modular Data Center
Installation Guide
7 Installing Air Conditioners
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7 Installing Air Conditioners
7.1 (Optional) Installing NetCol5000-A 25 kW Air
Conditioners
For details, see the document delivered with the equipment or obtain the required document
according to the section "Documentation Preparations".
If there are bases, install air conditioners on the bases.
The installation of air conditioner top frames applies to scenarios with top or bottom pipe routing.
Choose either scenario.
7.1.1 (Optional) Installing Top Frames (Top Pipe Routing)
Prerequisites
If the IT cabinet is 1200 mm deep, install top frames after installing air conditioner enclosure
frames.
Preparations
Tool: Phillips screwdriver
Procedure
Step 1 Remove the two M5x10 tapping screws that secure the front door sealing plate on the top of
the cabinet, as shown by (1) in Figure 7-1.
Step 2 Remove the rear decorative plate from the top frame, and then remove the four M5x10
tapping screws and the six M4x10 countersunk screws from the rear plate of the top frame, as
shown by (2) and (3) in Figure 7-1. Then remove the rear plate.
Step 3 Place the top frame and ensure that the side with FRONT faces upwards toward the cabinet
front door, as shown by (4) in Figure 7-1.
