If the door box rubs against the fixing screws in the top panel of the cabinet, remove the
screws in the top panel, and secure the top panel and the door box to the cabinet using the
screws.
----End
10.5.4 Installing Revolving Doors (Single-Row and Dual-Row
2200 mm)
Preparations
Tools: adjustable wrench, torque wrench, Phillips screwdriver, socket wrench, step ladder
Materials: revolving doors and accessories
Procedure
Step 1 Assemble the door frame.
1. Place the door posts and upper frame mounting kit on the floor, pull the post side plates
from the ends of the door posts, and remove the side plates, as shown by (1) and (2) in
Figure 10-53.
2. Assemble the door frame by connecting the two door posts and upper frame mounting kit
with eight M6 screw assemblies, as shown by (3) in Figure 10-53.
3. After the assembly is complete, verify that the posts are flush with the upper frame
mounting kit.
