FusionModule2000 Smart Modular Data Center
Installation Guide
10 Installing the Aisle Containment
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10.2 Installing Sealing Plates Around a Column (in
Scenarios with a Column)
Prerequisites
The adjustable skylight and cable tray in the scenario with a column have been installed.
Context
Because of the column, it is inevitable that certain cabinet places in the smart module are not
suitable for installing cabinets. Therefore, sealing plates need to be installed to ensure the air
tightness of the aisle containment.
Secure the sealing plates away from the aisle by combining them with the cabinet to keep the
elegance of the smart module. Stand outside the smart module during installation.
Table 10-2 Sealing plate types
300 mm wide, 2000 mm high sealing plate
600 mm wide, 2000 mm high sealing plate
800 mm wide, 2000 mm high sealing plate
300 mm wide, 2200 mm high sealing plate
600 mm wide, 2200 mm high sealing plate
800 mm wide, 2200 mm high sealing plate
Preparations
Tools: Phillips screwdriver, hammer drill
Materials: sealing plates and accessories, plastic expansion bolts, washers
Procedure
Step 1 Determine the positions of sealing plates, directions of the concave sides of sealing plates, and
the area covered by the adjustable skylight based on the actual installation environment.
Step 2 Install the sealing plates near the aisle.
Install the sealing plates near the aisle containment first, and then the sealing plates near the smart
module exterior.
1. Secure the two sealing plates using three M6 screws and nuts.
2. Place the connected sealing plates at the specified installation position, facing the correct
direction.
