FusionModule2000 Smart Modular Data Center
Installation Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8 Combining Cabinets
Prerequisites
If there are bases, the bases are leveled and cabinets are placed on the bases.
Preparations
Tools: adjustable wrench, level, Phillips screwdriver
Document: cabinet layout diagram
Procedure
Step 1 (Optional) Partially secure the cabinets to the bases.
If bases are required, perform this step for the PDC, network cabinet, IT cabinet, 600 mm wide air
conditioner, and 300 mm wide M-type air conditioner with feet.
If bases are required, go to Step 3 for cabinets without feet.
1. Align the mounting holes on the cabinet with those on the base.
2. Insert M12x80 screw assemblies into the mounting holes for the cabinet and base, and
partially tighten the screws.
