FusionModule2000 Smart Modular Data Center
Installation Guide
15 Installing Monitoring Devices
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Keep the protruding plane of the baffle plate flush with the end plane of the pad mounting kit.
Step 3 Remove the M2.5 screws (set aside) of the fingerprint and card reader and take off the
baseplate, as shown by (3) and (4) in Figure 15-49.
Step 4 Secure the baseplate to the baffle plate using two M3x8 countersunk screws, as shown by (5)
in Figure 15-49.
Step 5 Route the fingerprint and card reader cable through the cable hole in the baffle plate, as shown
by (6) in Figure 15-49.
Step 6 Secure the fingerprint and card reader to the baseplate, as shown by (7) and (8) in Figure
15-49.
----End
15.4.9.2 (Optional) Installing a Fingerprint and Card Reader with a Keypad
Context
The BOM number of a fingerprint and card reader with a keypad is 02070174.
Preparations
Tool: Phillips screwdriver
Materials: fingerprint and card reader with a keypad and accessories
Procedure
Step 1 Remove the baffle plate from the installation position, as shown by (1) in Figure 15-50.
