FusionModule2000 Smart Modular Data Center

Installation Guide

6 Installing the Network Cabinet, IT Cabinet, and Battery

Cabinet

Issue 02 (2018-03-31)

Huawei Proprietary and Confidential

6 Installing the Network Cabinet, IT

Cabinet, and Battery Cabinet

6.1 Moving the Network Cabinet, IT Cabinet, and Battery

Cabinet

Preparations

Tool: adjustable wrench

Procedure

Step 1 Move the cabinet to the planned installation position.

Step 2 Remove the screws that secure the cabinet to the pallet.

If the cabinet needs to be secured, save the screws you removed from the pallet for future use.
