FusionModule2000 Smart Modular Data Center
Installation Guide
14 Installing Power Supply and Distribution Devices
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Preparations
Tools: Phillips screwdriver, pallet truck, wrench, protective gloves
Materials: insulation tape, battery, copper bar or cable
Documents: battery wiring diagram, documents delivered with the batteries
Skill requirement: personnel qualified for installing batteries
Procedure
Step 1 Use a pallet truck to move batteries to a position near the installation position.
Step 2 Unpack the batteries.
Step 3 Install the batteries from bottom to top on the battery rack based on the battery wiring
diagram.
Due to space limitation, connect power cables after placing batteries on one layer.
Step 4 Connect power cables to batteries based on the battery wiring diagram.
----End
Follow-up Procedure
Verify the battery cable connections. Ensure that the battery quantity and cable connections
comply with the design and the cables or copper bars are reliably installed.
14.4 (Optional) Installing an Air Conditioner PDB
For details, see the document delivered with the equipment or obtain the required document
according to the section "Documentation Preparations."
In the scenarios with a smart busway or precision PDC, install a power distribution box (PDB) to supply
power to air conditioners.
The air conditioner PDB weighs about 44 kg. It is recommended that it be installed on a
concrete wall that is at least 70 mm thick.
