13 (Optional) Installing Dehumidifiers

Prerequisites



The aisle containment structure has been installed.



Air conditioners have been installed.

Context

The dehumidifier structure diagram is for reference only. The actual product prevails.

Figure 13-1 External structure of a dehumidifier

(1) Mounting ear

(2) Air filter

(3) Control panel

(4) Castor

(5) Water outlet

(6) Handle

(A) Air intake vent

(B) Air exhaust vent
