FusionModule2000 Smart Modular Data Center
Installation Guide
3 Smart Module Layout Requirements
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3.3 Layout Requirements for Dual-Row Aisle
Containment with a Column
This section describes the column position in the scenario with a column relative to the
adjustable skylight, sealing plates, and cable trays.
Figure 3-3 Legend
(2) Single layer of cable
tray
(3) Double layer of cable
trays
(4) Flat or rotating skylight
(7) Column in the equipment
room
If a column in the data center is irregular, ensure that the maximum cross section of the
column does not interfere with cabinets.
