FusionModule2000 Smart Modular Data Center

Installation Guide

17 Connecting Cables

Issue 02 (2018-03-31)

Huawei Proprietary and Confidential

274

Figure 17-9 Routing power cables and signal cables

(1) Network cabinet

(2) Optical fiber

(3) Signal cable

(4) Smart ETH gateway

(5) PDC

(6) Power cable

17.4 Cable Routes for the Single-Row Aisle Containment

Scenario (Power Supply and Distribution Cabinet)

Ensure that strong-current cables and weak-current cables are at least 100 mm away from

each other.
