FusionModule2000 Smart Modular Data Center

Installation Guide

4 (Optional) Installing Bases

Issue 02 (2018-03-31)

Huawei Proprietary and Confidential

Figure 4-10 300 mm wide air conditioner base

Preparations

Tool: Phillips screwdriver

Material: air conditioner base (300 mm wide)

Document: base installation position diagram

Procedure

Step 1 Remove the four M6 screws from adjustable feet and set them aside.

Figure 4-11 Removing screws from adjustable feet

Step 2 Move the adjustable feet to the mounting holes on the base according to the depth of the air

conditioner.
