Huawei FusionModule2000 User Manual

FusionModule2000 Smart Modular Data Center
Installation Guide
15 Installing Monitoring Devices
Issue 02 (2018-03-31)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
243
Step 3 Attach the antenna to the skylight connective plate or the top plate of the network cabinet
outside the aisle containment. Connect the antenna cable to the antenna port on the modem.
Do not use the antenna delivered with the modem.
Step 4 Connect one end of the serial port cable to the serial port on the GSM modem, and connect
the other end to an idle port on the RH2288 server.

For the connection method, see the documents delivered with the modem.

If the serial port on the RH2288 server does not match the connector of the serial port cable, use the
serial port cable adapter delivered with the modem.
Step 5 Connect one end of the power adapter to the modem and the other end to the 220 V power
supply through a power connector.

Use the power adapter delivered with the modem.

For the connection method, see the documents delivered with the modem.
----End
