FusionModule2000 Smart Modular Data Center

Installation Guide

D Acronyms and Abbreviations

Issue 02 (2018-03-31)

Huawei Proprietary and Confidential

309

Fast Ethernet

iBAT

ibattery

Integrated Circuit

Internet Technology

NTC

Negative Temperature Coefficient

PDC

Power Distribution Cabinet

PDU

Power Distribution Unit

Protective Earthing

PoE

Power over Ethernet

PP-R

Polypropylene Random

PVC

Polyvinyl Chloride

Secure Digital

SIM

Subscriber Identity Module

UPS

Uninterruptible Power System

VCN

Video Cloud Node

WiFi

Wireless Fidelity
