Terminal Identity Denition
R-LED Control card reader LED lights
R-D1 Card reader data 1
R-D0 Card reader data 0
R-Gnd Card reader public ground
R-12V Reader power + 12 V
Table 4-35 Lock and door magnetic terminal
denition
Terminal Identity Denition
LK+ Lock output power +
LK- Lock output power -/Passive output -
NP Passive output +
LKS Lock signal input +
ST Door magnetic signal input +
Gnd Common ground
Table 4-36 Alarm input terminal denition
Terminal Identity
Denition
AL(1-2) Two-door controller, no power supply
output signal
Gnd Common ground
Table 4-37 Power terminal
denition
Terminal Identity
Denition
LK-P +12V Lock the power input
+ 12 V
GND Lock the power input -
BAT + Battery +
- Battery -
DC +12V Controller + 12 V DC
power input
