Intel S7000FC4UR Technical Product Specification

BIOS User Interface ESB2 BMC Core TPS
Revision 1.0
Intel order number E18291-001
162
Setup Item Options Help Text Comments
Current
Configuration
<Current Memory
Configuration>
Information only
Displays one of the following:
 Maximum Performance Mode: System
memory is configured for optimal
performance and efficiency. No RAS
features are enabled.
 Single Channel Mode: System memory
is functioning in a reduced efficiency
failsafe mode.
 Memory Mirroring Mode: System
memory is configured for maximum
reliability in the form of memory
mirroring.
 Dual-DIMM Sparing Mode: System
memory is configured for optimal
performance and efficiency. Sparing is
also enabled.
Current Memory
Speed
<Installed Memory
Operating Speed>
Information only
Displays the speed the memory is currently
running at:
 533 MT/s (266MHz): System memory
is configured to operate at 266MHz
frequency.
 667 MT/s (333MHz): System memory
is configured to operate at 333MHz
frequency.
Memory RAS and
Performance
Configuration
Configure memory
RAS (Reliability,
Availability, and
Serviceability) and view
current memory
performance
information and
settings.
Select to configure Memory RAS and
performance. Takes the user to a sub-menu
screen.
Memory Riser Board
<n> Information
View Memory Riser
Board and associated
FB-DIMM information.
Select to view information about the specific
memory riser board. Takes the user to a sub-
menu screen.
