Intel® Server System S7000FC4UR TPS BIOS Role in Server Management
Revision 1.0
215
Offset Name Length Value Description
0 = Reserved
Bit 3
1 = Socketed
Bits 2:0
Cache level, zero-based
07h Maximum
Cache Size
Word Varies Bit 15
0 = 1K granularity
1 = 64K granularity
Bits 14:0
Max size in granularity
09h Installed Size Word Varies Bit 15
0 = 1k granularity
1 = 64k granularity
Bits 14:0
Installed size in granularity
Set to 0 if no cache or processor
installed.
0Bh Supported
SRAM Type
Word Bit Field See the System Management BIOS
Reference Specification, Version 2.5
Section 3.3.8.1 for values.
0Dh Current SRAM
Type
Word Bit Field See the System Management BIOS
Reference Specification, Version 2.5
Section 3.3.8.1 for values.
0Fh Cache Speed Word Varies In nanoseconds. Set to 0 if unknown.
10h Error
Correction
Type
Byte Enum See the System Management BIOS
Reference Specification, Version 2.5
Section 3.3.8.2 for values.
11h System Cache
Type
Byte 05h 05h = Unified cache
12h Associativity Byte Enum See the System Management BIOS
Reference Specification, Version 2.5
Section 3.3.8.4 for values.
18.5.3.7 Type 8 Structure — Port Connector Information
The SMBIOS Type 8 structure provides the attributes for all internal and external ports or
connectors in the server. There is one type 8 structure for each port / connector.
18.5.3.8 Type 9 Structure — System Slots
The SMBIOS Type 9 structure describes the attributes of the expansion slots in the server. One
Type 9 structure is present for each slot in the server.
18.5.3.9 Type 10 Structure — Onboard Devices Information
The SMBIOS Type 10 structure defines the attributes of devices integrated into the server
board. One Type 10 structure is present for each integrated device on the server board.
