Intel® Server System S7000FC4UR TPS Sensors
Revision 1.0
295
Sensor Name
3
Sensor # Sensor Type Event /
Reading Type
Event Offset
Triggers
Contrib. To
System Status
Assert /
De-assert
Readable
Value /
Offsets
Event
Data
Rearm Stand-
by
Presence OK X
Failure Degraded
A/C lost Degraded
Power Supply Status
4
2
71h Power Supply
08h
Sensor
Specific
6Fh
Configuration
error
OK
As and
De
– Trig
Offset
A
PS1 Temp 72h Temperature
01h
Threshold
01h
[u,l] [c,nc] nc =
Degraded
c = Non-fatal
As and
De
Analog R, T A X
PS2 Temp 73h Temperature Threshold
01h
[u,l] [c,nc] nc =
Degraded
c = Non-fatal
As and
De
Analog R, T A X
Mem Riser A PWRGD
Fail
78h Power Supply
08h
Digital
Discrete 03h
PWR Good Fail Fatal As 01h Trig
Offset
M –
Mem Riser B PWRGD
Fail
79h Power Supply
08h
Digital
Discrete 03h
PWR Good Fail Fatal As 01h Trig
Offset
M –
Mem Riser C PWRGD
Fail
7Ah Power Supply
08h
Digital
Discrete 03h
PWR Good Fail Fatal As 01h Trig
Offset
M –
Mem Riser D PWRGD
Fail
7Bh Power Supply
08h
Digital
Discrete 03h
PWR Good Fail Fatal As 01h Trig
Offset
M –
Baseboard PWRGD
Fail
7Ch Power Supply
08h
Digital
Discrete 03h
PWR Good Fail Fatal As 01h Trig
Offset
M –
SAS BP PWRGD Fail 7Dh Power Supply
08h
Digital iscrete
03h
PWR Good Fail Fatal As 01h Trig
Offset
M –
IO Riser PWRGD Fail 7Eh Power Supply
08h
Digital
Discrete 03h
PWR Good Fail Fatal As 01h Trig
Offset
M X
System ACPI Power
State
82h System ACPI
Power State
22h
Sensor
Specific
6Fh
S0 / G0
S1
S3
S4
S5 / G2
G3 mechanical off
OK As – Trig
Offset
A X
