Intel S7000FC4UR Technical Product Specification

Sensors ESB2 BMC Core TPS
Revision 1.0
Intel order number E18291-001
294
Sensor Name
3
Sensor # Sensor Type Event /
Reading Type
Event Offset
Triggers
Contrib. To
System Status
Assert /
De-assert
Readable
Value /
Offsets
Event
Data
Rearm Stand-
by
Mem Brd A-D Temp 40h – 43h Temperature
01h
Threshold
01h
[u,l] [c,nc] nc =
Degraded
c = Non-fatal
As and
De
Analog R, T A _
Mem A-B and C-D
Aggregate Temps
48h – 49h Temperature
01h
Threshold
01h
_ _ _ Analog _ _ _
Tach Fan Sensors 50h – 57h Fan
04h
Threshold
01h
[l] [c,nc] nc =
Degraded
c = Non-fatal
2
As and
De
Analog R, T M –
Fan Present Sensors 60h – 65h Fan
04h
Generic
08h
Device present OK As and
De
– T A –
Reserved for BMC
internal use
6Ch –
6Eh
– – – – – – – – –
Fully redundant OK X
Redundancy lost Degraded
Non-red: suff res
from redund
Degraded
Non-red: suff from
insuff resources
Degraded
Non-red: suff from
insuff resources
Degraded
Non-red:
insufficient
resources
Non-fatal
Redun degrade
from full
Degraded
Fan Redun-dancy
4
6Fh Fan
04h
Generic
0Bh
Redun degrade
from non-
redundant
Degraded
As and
De
– Trig
Offset
A
Presence OK X
Failure Degraded
A/C lost Degraded
Power Supply Status
4, 1
70h Power Supply
08h
Sensor
Specific
6Fh
Configuration
error
OK
As and
De
– Trig
Offset
A
