CK721-A Installation and Operation CK721-A User Interface
24-10349-8 Rev. B 4-27
This document contains confidential and proprietary information of Johnson Controls, Inc.
© 2012 Johnson Controls, Inc.
Access Grant on
Door Open Only
Toggle If enabled (Y), will report normal access granted
only if door is opened.
When enabled (Y) th
e Keyless Override timer
starts after swiping a badge (with override
privileges) and immediately opening the door.
When disabled (N), the Keyless Override timer
starts after swiping a badge (with override
privileges).
In the case of an elevator reader, when this flag
is e
nabled the Elevator Access Grant message
will be sent to the P2000 server only when the
cardholder presents a badge at the reader and a
valid floor is selected.
Re-lock on Door
Ope
n
Toggle If enabled (Y), this option modifies the
Anti-Tailgate feature to lock the strike when the
door opens. When the door closes, the shunt
time is cancelled.
This option requires the Anti-Tailgate Enabled
flag
to be set to (Y), and the use of the RDR2
module, firmware version PS-201E or later, or an
S300-DIN module.
This option should not be used with the “Timed
Ove
rride/Anti-Tailgate” option because “Timed
Override/Anti-Tailgate” can only work when the
door closes, and not when the door opens
(shunting of the door contact is cancelled at the
same time as “Timed Override/Anti-Tailgate is
cancelled”).
Timed Shunt Togg l e If enabled (Y),
all Timed Overrides only extend
the shunt time. The Access Time is not affected.
This option requires the use of RDR2 module,
firm
ware version PS-201E or later, or tan
S300-DIN module.
When Timed Shunt is enabled, it is
r
ecommended to also set the terminal’s
Anti-Tailgate Enabled flag to (Y), and the panel’s
Timed Override/Anti-Tailgate flag to (Y). This
way the door contact will never be shunted when
the door is locked and closed.
Override Time User Def. If a badge with the Local Override flag set is
presented at the reader
, the door will be put into
timed override. Value range: 0 to 1440 min. A
value of 0 turns the feature off.
For security reasons, this feature should only be
use
d together with the Timed Shunt option.
Table 4-8: Terminal Screen, Page 3
Field Type Description
