Analog input alarm MinAlarm IN8 Internal Min. and max. alarm signals of the
analog inputs 1 to 4
Ö Chapter 12.5 Analog inputs
IN8, IN9, IN10, IN11 Page 75
MaxAlarm IN8
MinAlarm IN9
MaxAlarm IN9
MinAlarm IN10
MaxAlarm IN10
MinAlarm IN11
MaxAlarm IN11
Ext. analog input
alarm
MinAlarm Ext. AI 1 Internal Min. and max. alarm signals of the
ext. analog inputs 1 to 8
Ö Chapter 12.18 External analog
inputs Page 143
MaxAlarm Ext. AI 1
MinAlarm Ext. AI 2
MaxAlarm Ext. AI 2
MinAlarm Ext. AI 3
MaxAlarm Ext. AI 3
MinAlarm Ext. AI 4
MaxAlarm Ext. AI 4
MinAlarm Ext. AI 5
MaxAlarm Ext. AI 5
MinAlarm Ext. AI 6
MaxAlarm Ext. AI 6
MinAlarm Ext. AI 7
MaxAlarm Ext. AI 7
MinAlarm Ext. AI 8
MaxAlarm Ext. AI 8
Math alarm MinAlarm Math 1 Internal
Ö Chapter 12.15 Math/logic Page
138
MaxAlarm Math 1
MinAlarm Math 2
MaxAlarm Math 2
MinAlarm Math 3
MaxAlarm Math 3
MinAlarm Math 4
MaxAlarm Math 4
MinAlarm Math 5
MaxAlarm Math 5
MinAlarm Math 6
MaxAlarm Math 6
MinAlarm Math 7
MaxAlarm Math 7
MinAlarm Math 8
MaxAlarm Math 8
Digital alarms Digital alarm 1 to 7 Internal Alarms for connected potential-free
contacts 1to7
Ö Chapter 12.4 Digital inputs
IN1to7 Page 74
