102 JVL Industri Elektronik A/S - User Manual - Integrated Stepper Motors MIS23x, 34x, 43x
6.4 Gear Mode
After this program has been executed, the external source must be connected to the fol-
lowing inputs:
Please note that the MIS motor family offers different connector configurations.
For specific details about at which connectors the I/O terminals are available please con-
sult:
- Connector overview for the MIS23x, page 33 - or
- Connector overview for the MIS34x, page 35.
6.4.5 General considerations concerning cabling.
It is strongly recommended that shielded cable is always used when connecting the ex-
ternal pulse source to the pulse input to ensure that no noise from the surroundings af-
fect the quality of the signal and worst case cause the motor movement to get affected.
Also a good, solid ground wire between the motor and the source is recommended since
any differences in the potential between the pulse source and the motor can affect the
motor movement.
General guidelines concerning the I/O’s are given in the following chapters:
- Inputs, page 16 or General, page 24.
MIS34x and MIS43x motor family
Quadrature format I/O terminal Pulse/direction format I/O terminal
Channel A IO2 Pulse IO2
Channel B IO3 Direction IO3
