JVL MIS23 Series User Manual

280 JVL Industri Elektronik A/S - User Manual - Integrated Stepper Motors MIS23x, 34x, 43x
13.4 Torque Curves
13.4.1 MIS23x and MIS34x Torque curves
Below the torque performance for both motor families is shown. As it can be seen the
supply voltage have a significant influence at the torque performance at higher speeds.
Please make sure to use a supply voltage which is appropriate for the actual application.
Also make sure that the supply voltage is stable without too much ripple since voltage
dips can cause the motor to stall and loose position.
0
30
60
90
120
150
180
210
240
270
300
330
360
390
420
450
480
0
0,5
1
1,5
2
2,5
3
3,5
0 200 400 600 800 1000
Torque (Nm)
Speed (RPM)
MIS231, 232 & 234 motortorqueversus speed and supply voltage
MIS234 @48V
MIS234 @24V
MIS232 @48V
MIS232 @24V
MIS231 @48V
MIS231 @24V
Power supply = PSU24-240 (24V/240W regulated PSU)
Power supply = PSU48-240 (48V/240W regulated PSU)
Room temperature = 20°C
Torque (oz-in)
TT222
3
-0
3
GB
0
1
2
3
4
5
6
7
8
9
10
0 500 1000 1500 2000 2500
Torque (Nm)
Speed (RPM)
MIS340, 341 & 342 motor torqueversus speed and supply voltage
MIS342 @80V
MIS342 @48V
MIS342 @24V
MIS341 @80V
MIS341 @24V
MIS340 @80V
MIS340 @48V
MIS340 @24V
Power supply = PSU24-240 (24
V
/240W regulated PSU)
Power supply = PSU80-4 (80
V
/400W unregulated PSU)
Room temperature = 20°C
Power supply = PSU24-240 (24V/240W regulated PSU)
Power supply = PSU80-4 (80V/400W unregulated PSU)
Power supply = PSU48-1000-01 (48V/1000W regulated PSU)
Room temperature = 20°C
T
Torque (oz-in)
