15.4 Gear and brake mounting instruction
TT1537-01GB
3
Step 3 - Final stage. Fasten the shaft collar with a torque of according to
the scheme below.
Please notice that it can be fatal not to use the specified torque since the
shaft may slip over time and cause a position offset.
Use a precise torque wrench
to fasten the screw in the shaft collar.
Gears
(Product type to be mounted)
Brakes
(Product type to be mounted)
HTRG05
MAB23x
HTRG05
MAB23x
HTRG06
MAB34x
HTRG06
HTRG08
HTRG08
HTRG08
HTRG10
MAC050 to MAC141
(Ø6.35 shaft)
MAC050 to MAC141
(Ø6.35 shaft)
MIS230-233
(Ø6.35 shaft)
MIS230-233
(Ø6.35 shaft)
MAC050 to MAC141
(Ø6.35 shaft)
MAC400-402
(Ø14 shaft)
MIS340-341
(Ø9.53 shaft)
MIS340-341
(Ø9.53 shaft)
MIS342
(Ø14 shaft)
MAC800
(Ø19 shaft)
MAC800
(Ø19 shaft)
Series
Series
Used with motor type Tool
ToolUsed with motor type
Torque
(F1)
Torque
(F1)
5Nm
Hex size 2.5
Hex size 2.5
Hex size 3
Hex size 3
Hex size 3
Hex size 3
Hex size 3
Hex size 4
Hex size 5
Hex size 5
Hex size 5
2Nm
5Nm
2Nm
5Nm
5Nm
11Nm
5Nm
8Nm
11Nm
11Nm
