JVL MIS23 Series User Manual

282 JVL Industri Elektronik A/S - User Manual - Integrated Stepper Motors MIS23x, 34x, 43x
13.5 Physical Dimensions
13.5.1 Physical dimensions MIS231, MIS232 and MIS234
Only MIS23x
20,6 ±0.5
Ø 38.1 ± 0.025
Shaft dia.
1.6
5.0
54.5
47 ± 0.2
56.4
47 ± 0.2
56.4
4 x Ø5.0
Ø66.67
MIS231 MIS232 MIS234
96.0[3.78]
118.5[4.67]
154.0[6.06]
140[5.51]
162.5[6.40]
198[7.80]
Motor Type Length Length including
±2.0 [0.0787]
Connectors
Shaft dia.
+0 / -0.013mm[0.000512]
6.35[0.25] 6.35[0.25]
10.0[0.3937]
6
0
.
0
6
6
.
0
All dimensions in mm unless other is noted.
TT2321-02GB
44
L
D
[ ] = Inches
L
D
