296 JVL Industri Elektronik A/S - User Manual - Integrated Stepper Motors MIS23x, 34x, 43x
15.3 Brakes and shaft reinforcement
2 brake units are available for the MIS231 and MIS232 motors. MIS234 has a 10 mm out-
put shaft and the MAB23 can therefore not be mounted. The MAB23x-01 offers a 10mm
output shaft and MAB23x-02 offers a 6.35mm output shaft. Both types can be mounted
directly on all the MIS231 and MIS232 motors and require 24VDC applied to release the
motor
See also the data-sheet LD0055-xx which can be downloaded from www.jvl.dk.
