JVL Industri Elektronik A/S - User Manual - Integrated Stepper Motors MIS23x, 34x, 43x 279
13.3 SMC75 Technical Data
13.3.1 SMC75 Technical data
Power supply Condition Min. Norm. Max. Unit
P+ - P- 12 48 V
P+ supply current
(No load)
@ 24V
@ 48 V
125
100
mA
(RMS)
CV 7 32 V
CV supply current
(Unconnected I/O)
@12V
@24V
160
90
mA
mA
V+ for CAN 4.5 5 5.5 V
V+ supply current for CAN 1 mA
User outputs O1-O8
Output source current pr. channel CV = 24VDC
@ 8 sourcing
@ 4 sourcing
@ 1 sourcing
75
100
350
mA
mA
mA
Output sink current 0 mA
Output voltage @ 100mA CV – 2,4 CV- 2.2 V
User inputs I1-I8
Input impedance 10 kOhm
Voltage applied to any input -0.5 22 V
Analogue input nominal 0 5.0 V
Logic “0” 0 0.9 V
Logic “1” 1.9 22 V
RS232 (5V)
Tx output low level 0.45 1 V
Tx output high level 4 4.55 V
Tx output source current 1 mA
Tx output sink current 1 mA
Rx input low level -0.5 0.9 V
Rx input high level 1.9 48 V
RS422
Input (V
B1+
-V
B1-
)± 0.2± 6V
Input leakage current 0.7 1 mA
Output (V
A1+
-V
A1-
) @ 50 ohm ± 1.1 ± 2.2 ± 5,0 V
Output source current 60 mA
RS485
Input (V
A-
-V
B-
)± 0.2± 12V
Input leakage current 0.7 1 mA
Output (V
A-
-V
B-
) @ 50 ohm ± 1.5 ± 2.5 ± 5.0 V
Output source current 60 mA
CAN (ISO 11898-24V)
Voltage at any input -36 36 V
Input (V
CAN_H
- V
CAN_L
)Dominant0.9 5 V
Input (V
CAN_H
- V
CAN_L
) Recessive -1.0 0.5 V
Output (V
CAN_H
- V
CAN_L
) Dominant 1.5 3.0 V
Output (V
CAN_H
- V
CAN_L
) Recessive -500 50 mV
Only SMC75
