JVL MIS23 Series User Manual

332 JVL Industri Elektronik A/S - User Manual - Integrated Stepper Motors MIS23x, 34x, 43x
16.10 MST Motor Ordering Information
Quickstep MST motor selection chart
MST 234 A 23 3 - M1 AA 3.0
Revision Sep 2010
MST Motor Stepmotor with housing but without electronics IP55
81
82
110 NEMA11 1/2 stack 32mm
111 NEMA11 1 stack 32mm
114 NEMA11 2 stack
170 NEMA 17 1/2 stack
171 NEMA 17 1/2 stack
172 NEMA 17 1/2 stack
173 NEMA 17 1/2 stack
174 NEMA 17 1/2 stack
175 NEMA 17 1/2 stack
176 NEMA 17 0,8Nm
230 NEMA23 s tepmotor
231 NEMA23 s tepmotor
232 NEMA23 s tepmotor
234 NEMA23 s tepmotor
340 NEMA34 s tepmotor
341 NEMA34 s tepmotor
342 NEMA34 s tepmotor
432 NEMA43 s tepmototor
513 NEMA51 s tepmototor
A For 3,0Amp driver/controller and motor 200step
/
rev
B For 6,0Amp driver/controller and motor 200step
/
rev
C For 9,0Amp driver/controller and motor 200step
/
rev
D For 12,0Amp driver/controller and motor 200step
/
rev
F For 3,0 Amp driver/controller and motor 400step
/
rev
G For 6,0 Amp driver/controller and motor 400step
/
rev
H For 9,0 Amp driver/controller and motor 400step
/
rev
1 6.35mm shaft and IP42. Round shaft.
2 6.35mm shaft and IP65 (motor shaft and body) IP66 (Rear end and connector) and special painting
3 10,0 mm shaft and IP42
4 10.0mm shaft and IP65 (motor shaft and body) IP66 (Rear end and connector) and special painting
5 14mm shaft and IP42
6 14mm shaft and IP65 (motor shaft and body) IP66 (Rear end and connector) and special painting
7 8mm shaft 52mm long for HFOS worm gear. IP42
8 6.35mm shaft with D-cut and IP42
9 5.00 mm shaft with D-cut and IP42
10 7.00mm shaft 45.5 mm long for Dunker flange and IP42
11 6.35mm shaft . Black painted and rubber sealing in rear end IP65. Shaft end IP42.
12 9,53mm shaft D shape . Black painted. Shaft end IP42. Only MIS34x
13 9,53mm shaft D shape . Black painted. Shaft end IP42. Rear end shaft ø10mm 30mm long D shape. Only MIS34x
14 14mm with 5x5 key shaft. Black painted. Shaft end IP42. Only MIS34x
15 14mm with 5x5 key shaft. Black painted. Shaft end IP42. Rear end shaft ø10mm 30mm long D shape. Only MIS34x
16 5.00 mm round shaft IP42
17 9,53mm shaft D shape . Black painted. Shaft and rear end IP65. Only MIS34x
18 9,53mm shaft D shape . Black painted. Shaft and rear end IP65. Rear end shaft ø10mm 30mm long D shape. Only MIS34x
19 14mm with 5x5 key shaft. Black painted. Shaft and rear end IP65. Only MIS34x
20 14mm with 5x5 key shaft. Black painted. Shaft and rear end IP65. Rear end shaft ø10mm 30mm long D shape. Only MIS34x
21 16mm with key 5x9mm (only for ???)
23 19mm with key 6x20mm (only for MIS43x
/
MST42x )
23 10mm Shaft IP67 , motor and housing and rear end IP67 (only MIS234)
1 USA producent (udgået)
2 Taiwan leverandør (TECO)
3 Kina leverandør (Fulling)
6 Taiwan leverandør (TECO) men producered på TECO fabrik i Kina
M1 M12 connector
W0 PG16 and no cable
W1 PG16 and 2m cable
X1 Special connector side mount
M3 8Leadwirelængde300mm
M4 8Leadwirelængde400mm
L3 4Leadwirelængde300mm
L4 4Leadwirelængde400mm
A
A
No magnetic c hip. Only specified if more to follow
H2 Magnetic encoder feedback. 256x4 pulses
/
rev. Only SMC75, SMC85, MIS23x and MIS34x
E1 Incremental encoder 500 ppr with index puls HEDS series
4.6
A
mpere
/
phase
0.6
A
mpere
/
phase
3.0
A
mpere
/
phase
2.0
A
mpere
/
phase
9.0
A
mpere
/
phase
P
A
Planet gear + model
A
: 36mm 36JX30K til Nema23
PB Planet gear + model B
T
A
Toothwheel gear
W
A
Wormgear
5.18 udveksling
MST 232 A 1 3 - M1
A
A
2.0 P
A
5.18
Examples Husk mellem rum hvis ikk e brugt
MST 176 A 16 3 - L3
A
A
3.0 Stepmotor NEM
A
23 with housing.
