6 I/O terminals
6.6 User-defined terminal assignment
368
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Configuration parameters for the inputs of the technology application
The following parameters can be used to change the preconfigured assignment of the application
inputs:
Example
Task:
Starting from the preset technology application "Actuating drive speed" and the "Terminals 0"
control mode, the DI2 digital input is to be used for choosing an alternative
acceleration/deceleration time for the main setpoint instead of for choosing the fixed setpoint 2/3.
To do this, the DI2 digital input is not to be linked to the bJogSpeed2 input but to the bJogRamp1
input of the application module.
Procedure:
1. Use the keypad to go to the menu level Applications  Actuating drive speed (conf.). This menu
level contains all the configuration parameters of the "Actuating drive speed" technology
application".
Configuration parameters ( 398)
2. Navigate to the configuration parameter LA_NCtrl: bJogSpeed2 (C00701/10) which represents
the logical signal link of the application input bJogSpeed2.
3. Change the setting of C00701/10
:
Change selection "16001: DigIn_bIn2" in selection "0: Not interconnected".
4. Navigate to the configuration parameter LA_NCtrl: bJogRamp1 (C00701/13
) which represents
the logical signal link of the application input bJogRamp1.
5. Change the setting of C00701/13
:
Change selection "0: Not interconnected" in selection "16001: DigIn_bIn2".
 Tip!
The example shows that, for each input of the application block, the associated
configuration parameter (C00700/x
or C00701/x) is only allowed to contain one source
that you enter.
Parameters Info
TA "Actuating drive speed": Configuration parameters ( 398)
C00700/x
Analog connection list
C00701/x
Digital connection list
TA "Table positioning":Configuration parameters ( 461)
C00710/x
Analog connection list
C00711/x
Digital connection list
TA "Switch-off positioning": Configuration parameters ( 488)
C00760/x
Analog connection list
C00761/x
Digital connection list
