CAB DISPLAY MODULE (CDM)
5. Press SELECT (D) until BACKLIGHTING is displayed
on the upper line.
• Default setting is displayed on the lower line.
6. Press left (B) or right (C) arrows to adjust
display bac klighting.
7. Press PROGRAM (A) to exit Programming Mode or
press SELECT (D) to pr oc ee d to next CAB DISPLAY
SETUP? action.
Figure 4.3
6: M105 Backlighting
Figure
4.37: M155 Backlighting
Figure 4.38: M205 Backlighting
147962 168 Revision A
