MacDon M Series - Lubricants, Fluids, and System Capacities

REFERENCE
6.4 Lubricants, Fluids, and System Capacities
CAUTION
To avoid injury or death, do not allow ANY machine fluids to enter the body.
Table 6.16 M105 System Capacities
Lubricant/Fluid Location Description Capacity
Grease
As required unless
otherwise specified
SAE multi-purpo se
High temperature extreme pressure
(EP2) performance With 1%
Max Molybdenum disulphide
(NLGI Grade 2) Lithium base.
Diesel fuel
Fuel tank
Diesel grade No.2, or Diesel grade
No.1and2mix
20
; refer to 6.5
Fuel Specifications, page 378 for
more information.
367 liters
(97 US gallons)
Hydraulic oil Hydraulic reservoir
SAE 15W-40 compliant with SAE specs
for API class CJ-4 engine oil which
meets or exceeds CES 20081 and API
performance classification CJ-4.
44 liters
(11.5 US gallons)
Gear lubricant
Wheel drive
21
SAE 75W-90, API service class GL-5.
Fully synthetic gear lubricant,
(SAE J2360 preferred).
1.4 liters
(1.5 US quarts)
Antifreeze
Engine c
ooling
system
ASTM D-6210 and
Fleetguard ES Compleat
®
See last page of this section
27.5 lit
ers
(7.3 US g
allons)
22
Engine oil Engine oil pan
SAE 15W-40 compliant with SAE specs
for API clas s S J and CH-4 e ng in e oil.
11.9 liters
(12.6 U S quarts)
23
Air conditioning
refrigerant
24
Air conditioning
system
R134A
2.27 kg (5 lb .)
Air conditioning
refrigerant oil
25
Air conditioning
system total
capacity
PAG SP-15 240 cc (8.1 fl.oz.)
Receiver drier
(MD #183273)
Air conditioning
system
PAG S
P-15
60 cc
(2 fl.oz.)
Condenser
(MD #138983)
Air conditioning
system
PAG SP-15 30 cc (1 fl.oz.)
20. Optional when operating temperature is b elow 0°C (32°F).
21. SAE 85W-140 API Service Cla ss GL-5. E xt re me Pressure G e ar Lubric an t is used before initial change.
22. Equal p a rts with water, h igh qu ality, soft, de-ionized or d istilled water as rec om mended by supplier.
23. Includes filter
24. For prior models who have not upgraded to 5 lb. of refrigerant order Kit MD #183180, w hich includes high
pressure switch and decal to advise of systems 5 lb. charge requirement. Refer to Service Bulletin 1254.
25. New compressor (MD #203013) comes filled. If installing on 201 4 and prior, refer to Service Bulletin 1254.
147962 374 Revision A
