ASSEMBLING THE W INDROWER
CAUTION
Check to be sure a ll bystanders have cleared t he area.
15. Start the eng ine and activate the HEADER DOWN
switch (A) on the GSL to fully lower the header.
16. Stop engine and remove key from ignition.
Figure 3.261: Ground Speed Lever
17. Connect h
eader drive hoses (A) and electrical
harness (
B) to header. Refer to the rotary disc header
operator
’s manual.
Figure 3.262: Header Drive Hoses and Harness
18. Connec
t the header drive hoses and electrical
harnes
s (A) to the header. Refer to the rotary disc
heade
r operator ’s manual.
Figure 3.263: Header Connections
Attaching an R-Series Header: Hydraulic Center-Link without Self-Alignment
DANGE
R
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove
the key from the ignition before leaving the operator ’s seat for any reason.
147962 138 Revision A
