MacDon M Series - Page 389

REFERENCE
Lubricant/Fluid
Location Description
Capacity
Evaporator
(MD #160130)
Air conditioning
system
PAG SP-15 60 cc (2 fl.oz.)
Hoses
Air conditio
ning
system
PAG SP-15 30 cc (1 fl.oz.)
Table6.17M155SystemCapacities
Lubricant/
Fluid Location Description
Capacity
Grease
As requ ire d unless
otherwise specified
SAE multi-purpos e high temp erature
extreme pressure (EP2) performance
with 1% max Molybdenum Disulphide
(NLGI Grade 2) lithium base
Diesel fuel
Fuel tank
Diesel Grade No.2, or Diesel Grade
No.1 and 2 mix
26
; refer to 6.5
Fuel Specifications, page 378 for
more information
378 liters
(97 US gallons)
Hydraulic oil Hydraulic reservoir
SAE 15W-
40 compliant with SAE specs
for A PI c
lass SJ and CH-4 en gin e oil.
65 liters
(17.2 US gallons)
Gearbox
SAE 80W-140
27
, API service clas s GL-5.
Fully synthetic gear lubricant,
(SAE J2360 preferred)
2.1 liters
(2.2 US quarts)
Gear lubricant
Wheel drive
28
SAE 75W-90, API service class GL-5.
Fully synthetic gear lubricant,
(SAE J2360 preferred)
1.4 liters
(1.5 US quarts)
Anti
freeze
Engine cooling
system
ASTM
D-6210 and
Flee
tguard ES Compleat
®
See l
ast page of this section
27.5 liters
(7.3 US gallons)
29
Engine oil Engine oil pan
SAE 15W-40 compliant with SAE specs
for API class SJ and CH-4 engine oil
11 liters
(11.6 US quarts)
Air
conditioning
ref
rigerant
30
Air
conditioning
sys
tem
R13
4A
2.27 kg (5 lb.)
Air conditioning
refrigerant oil
31
Air conditioning
system total
capacity
PAG SP-15 24 0 cc (8.1 fl.oz.)
26. Optional when operating temperature is below 0°C (32°F).
27. SAE 75W-140 may be substituted for SAE 80W-140 if necessary.
28. SAE 85W-140 API Service Class GL-5. Extreme Pressure Gear Lubricant is used before initial change.
29. Equal parts with water, high quality, soft, de-ionized or distilled water as recommended by Supplie r.
30. For prior models who have not upgraded to 2.27 kg (5 lb.) of refrigerant order Kit MD #183180, which includes
decal to advise of systems 2.27 kg (5 lb.) charge requirement. Refer to Service Bulletin 1254.
31. New compressor (MD #203013) comes filled. If installing on 2014 and prior, refer to Service Bulletin 1254.
147962 375 Revision A
