ASSEMBLING THE WINDROWER
8. Use the lifting device to slightly lift the header lift arms,
and remove the lifting bars (A) from the legs.
9. Relocate the spring locking pins (B) to the front of the
lift arms.
Figure 3.
12: Header Lift
147962 33 Revision A
