Crane operation
11.2 Standard slewing range type
11 - 26 3 302 819 en Operating manual
GMK3060
13.12.2018
Free-on-wheels
operating position
• Check that the truck crane has been rigged for free on wheels operation;
à CHECKLIST: Rigging, p. 12 - 1
• Enter the correct RCL code for the Free on wheels operating position in accord-
ance with the Lifting capacity table ;
à Entering the rigging mode, p. 11 - 36.
• Before slewing, check how much counterweight is rigged and unrig the coun-
terweight if necessary before slewing the superstructure;
à Slewing with a
rigged counterweight, p. 12 - 76.
G
Danger of overturning if the truck crane is free-standing!
The superstructure of free on wheels truck cranes may only be rotated if
the counterweight rigged on the turntable does not weigh more than 7.6 t
(16,700 lbs) and the radius permitted in the working area is maintained according
to Lifting capacity table.
In this way you prevent the truck crane tipping to the rear when slewing the
superstructure.
G
Danger of overturning if the truck crane is free on wheels and the RCL is
overridden!
If the RCL code for working free on wheels has been entered, when the working
radius is reached the RCL prevents those crane movements that would reduce
the radius any further. This is in order to provide stability to the rear.
The truck crane will overturn if you override the RCL and reduce the working
radius any further.
