Crane operation
11.4 Operation of the rated capacity limiter
11 - 34 3 302 819 en Operating manual
GMK3060
13.12.2018
11.4.1 Switching on the RCL
Switching on The RCL is switched on together with the ignition.
• Switch on the ignition.
A test program runs after switching on the ignition.
• Check whether you can hear a buzzer tone.
Lamp test
• Check that the lamps (1) light up after switching
on the ignition.
If one or more lamps do not light up, contact
Manitowoc Crane Care.
Brightness of the displays
The sensors (1) on the CCS and RCL displays have no function and the brightness
is not automatically regulated. The brightness of the display can be adjusted
manually.;
à p. 4 - 11.
G
Risk of accidents in the event of faulty safety devices!
If the lamps or buzzer fail, notify
Manitowoc Crane Care and have the error
corrected.
In the meantime, pay particular attention to the lamps in the event of a failure of
the buzzer tone and vice versa.
