Operating elements for crane operation
9.1 Overview of the operating elements
9 - 20 3 302 819 en Operating manual
GMK3060
13.12.2018
9.1.7 Menu-independent displays
1 Slewing gear à p. 9 - 112
2 Telescoping mechanism
à p. 9 - 116
3 Derricking gear
à p. 9 - 114
4 Main hoist
à p. 9 - 108
5 Auxiliary hoist
1)
à p. 9 - 110
6 Lattice extension derricking gear
1), 2)
7 Remote control display
1), 3)
8 Display time
9 Jog dial display
à p. 9 - 96
10 Error display
à p. 14 - 8
11 Warning messages display
à p. 14 - 3
1)
Additional equipment
2)
à Lattice extension operating manual
3)
à Separate operating manual
